Hebei Zhengneng Boiler Equipment Co., Ltd. was established in August 2013, is a focus on the development, production and sales of science and technology production enterprises.Our company has purchased laser CNC cutting machine, CNC drilling machine, automatic submerged arc welding, automatic cylinder circular seam welding machine, real-time online imaging testing and other advanced processing and testing equipment from home and abroad, which provides reliable guarantee for excellent product quality.
Why Choose Us
Professional technology
Backed by a dedicated R&D team, every product undergoes meticulous development and rigorous quality assurance, ensuring the highest level of professionalism and reliability.
Custom made
We offer a wide variety of specifications for you to choose from, and we also provide customized products tailored to your specific needs, ensuring comprehensive solutions to meet all your requirements.
Honors and Qualifications
The company has obtained an A2-level pressure vessel license, an A-level boiler manufacturing license, a pipeline pressure fitting license, and GB2 and GC2 pipeline installation licenses.
Our Service
The company has a comprehensive after-sales service network to provide full support for your needs.
|
Item\Type |
Fixed Grate Manual Coal Fired Hot Water Boiler |
|||
|
Rated capacity MW |
0.35 |
0.7 |
1.4 |
|
|
Rated working pressure MPa |
0.7 |
0.7 |
0.7 |
|
|
Supply water temperature ℃ |
95 |
95 |
95 |
|
|
Return water temperature ℃ |
70 |
70 |
70 |
|
|
Heated surface area m² |
Radiation / convection |
2.3/16.2 |
4.55/20.12 |
6.17/39.5 |
|
Suitable fuel type |
Coal / Wood / Charcoal / Jute / Fabric, ect. |
|||
|
Boiler heat efficiency % |
79.6 |
81 |
81.6 |
|
|
Fuel consumption kg/h |
76 |
146 |
290 |
|
|
Effective area of grate m² |
0.98 |
1.5 |
2.4 |
|
|
Transportation size of boiler mm |
Length |
2970 |
3782 |
4900 |
|
Width |
1950 |
1800 |
2130 |
|
|
Heigth |
2660 |
2870 |
3222 |
|
Types of Hot Water Boiler
High Temperature Hot Water Boilers (HTHW)
According to ASME, a High Temperature Hot Water Boiler is an ASME Section I Power Boiler and includes any boiler with a maximum temperature exceeding 250°F and/or maximum pressures exceeding 160 PSIG. In application, HTHW systems refer to those designs where the temperatures exceed 350°F.
Medium Temperature Hot Water Boilers (MTHW)
A Medium Temperature Hot Water Boiler refers to a boiler with a temperature, ranging from 250°F to 350°F, with a maximum operating pressure of 150 PSIG. This means that an MTHW system may require an ASME Section I boiler for some designs and an ASME Section IV boiler for others.
Low Temperature Hot Water Boilers (LTHW)
According to ASME Section IV, a heating boiler includes any boiler with a maximum temperature below 250°F and a maximum pressure below 160 PSIG. In application, LTHW systems refer to those designs where the temperatures are below 250°F.
Components of a Hot Water Boiler
Burner: This is where the mixing of air and the fuel source happens resulting in the combustion which provides the necessary heat to heat the water.
Combustion chamber: The burner creates combustion in the chamber that heats the heat exchanger.
Heat Exchanger: The heat from the combustion in the chamber passes through the heat exchanger to heat the water in the tank without any direct contact.
Ignition/Flame failure Control: This control initiates the ignition process on a demand from the operating control and monitors the burner flame during the trial for the ignition process during operation will shut off the fuel supply to the burner if a flame failure is detected.
Operating Control: A temperature control that cycles the burner off and on or modulates the burner to maintain the temperature setting of the control.
Circulating pump: The pump maintains water flow through the boiler to be heated and circulated to a variety of heating components such as convection heaters, coils in air handlers, or in-floor heating coils.
Application of Hot Water Boiler
Central heating of buildings
Hot water boilers are commonly used for space heating in residential, commercial, and office buildings through radiator and fan coil systems.
Domestic hot water heating
Boilers are responsible for supplying domestic hot water, which is used for showers, washing, and other household purposes.
Process water heating in industry
In certain industries that need water at medium or high temperatures, hot water boilers are used to heat process water.
Pools and recreation centers
Using hot water boilers for swimming pools is considered as one of the most effective methods of pool heating and is an ideal option for heating both residential and commercial pools.
• Flow Switch: Maintain optimal flow rates for maximum performance.
• On-Board Alarm: Stay informed and respond promptly to any operational issues.
• E-Stop: Prioritize safety with emergency stop functionality.
• BMS Alarm: Integrate with Building Management Systems for comprehensive monitoring.
• BMS Enable/Disable: Tailor system settings to suit specific requirements.
• BMS Remote Step Control: Manage operations remotely for unparalleled convenience.
• BMS Remote Set Point: Adjust settings remotely to optimize performance in real-time.

Our Certifications





FAQ
We're professional hot water boiler manufacturers and suppliers in China, specialized in providing high quality customized service. We warmly welcome you to buy hot water boiler at competitive price from our factory. Contact us for quotation.
